Delta · Ultron HPH
Delta Ultron HPH three-phase UPS
The Delta Ultron HPH is a three-phase UPS rated 20 to 200 kVA (HPH Gen2 20 to 40 kVA, 20 to 120 kW, 160 and 200 kVA).
Delta Ultron HPH: key facts
Delta lists the Ultron HPH as a current range.
- TypeThree-phase UPS
- Power range20 to 200 kVA (HPH Gen2 20 to 40 kVA, 20 to 120 kW, 160 and 200 kVA)
- StatusCurrent
- Service in CanadaPreventive maintenance, battery replacement and emergency repair, including discontinued units. 1 (438) 881-3363
Sources, checked October 3, 2026: Delta, Ultron HPH 20-120 kW; Delta, HPH Gen2 20-40 kVA.
How a three phase double conversion UPS carries the load, and where the bypass sits.
Ultron HPH models
The orderable configurations we supply and service:
| Model | Rating | Phase / Voltage | Part number | Status |
|---|---|---|---|---|
| Delta Ultron HPH-20K (20kVA Gen2) | 20 kW | 3ph 4-wire+G in/out 220/380-240/415V | HPH-20K | Current |
| Delta Ultron HPH-30K (30kVA Gen2) | 30 kW | 3ph 4-wire+G in/out 220/380-240/415V | HPH-30K | Current |
| Delta Ultron HPH-40K (40kVA Gen2) | 40 kW | 3ph 4-wire+G in/out 220/380-240/415V | HPH-40K | Current |
| Delta Ultron HPH-60K (60kVA) | 60 kW | 3ph 4-wire+PE in/out 380/400/415V | HPH-60K | Current |
| Delta Ultron HPH-80K (80kVA) | 80 kW | 3ph 4-wire+PE in/out 380/400/415V | HPH-80K | Current |
| Delta Ultron HPH-100K (100kVA) | 100 kW | 3ph 4-wire+PE in/out 380/400/415V | HPH-100K | Current |
| Delta Ultron HPH-120K (120kVA) | 120 kW | 3ph 4-wire+PE in/out 380/400/415V | HPH-120K | Current |
| Delta Ultron HPH-160K (160kVA) | 150 kW | 3ph 4-wire+G in/out 220/380-240/415V | HPH-160K | Current |
| Delta Ultron HPH-200K (200kVA) | 200 kW | 3ph 4-wire+G in/out 220/380-240/415V | HPH-200K | Current |
Specifications
Efficiency & reliability
The Ultron HPH is a true online double-conversion three-phase UPS (20 to 120 kW) with 96% AC-AC efficiency online, 99% in ECO mode, low input THD under 3% and unity power factor (kVA = kW), so a given frame carries full kW with little upstream distortion. Reliability features include a watch-dog design, and a swappable interior architecture with front-access servicing makes maintenance quick. Delta aims it at small and medium data centres and mission-critical applications, naming factory equipment, communication systems, computer networks, medical systems and monitoring systems.
Source: Delta, Ultron HPH product page and features. Figures are Delta's published specifications.
Batteries and battery cabinets for the Delta Ultron HPH
Battery strings and cabinets depend on the configuration and runtime. Sealed VRLA blocks for Delta battery cabinets are in this sealed UPS battery range.
Delta Ultron HPH service in Canada
We service the Delta Ultron HPH across Canada: preventive maintenance, battery replacement and emergency repair, including units the manufacturer no longer supports. We are a Canadian UPS service and supply provider, working on three-phase systems since 2012.
- Phone: 1 (438) 881-3363
- Email: info@threephaseups.ca
- Coverage: across Canada, in English and French
Repairs on running and out-of-warranty units are handled under Delta Ultron HPH service and repairs.
Sizing, redundancy and custom builds
We engineer the solution: load and growth analysis, redundancy (N, N+1, 2N), runtime and battery sizing, paralleling and switchgear, and custom configurations where the standard catalogue doesn't fit. Because we supply every major brand, the Ultron HPH is one option we weigh on its merits, not the only answer.
Common questions
What is the Delta Ultron HPH?
The Delta Ultron HPH is a three-phase UPS rated 20 to 200 kVA (HPH Gen2 20 to 40 kVA, 20 to 120 kW, 160 and 200 kVA).
Is the Delta Ultron HPH discontinued?
No. Delta lists the Ultron HPH as a current range.
Who services the Delta Ultron HPH in Canada?
A Canadian UPS service and supply provider, in business since 2012, services the Delta Ultron HPH across Canada: preventive maintenance, battery replacement and emergency repair, including discontinued units. Call 1 (438) 881-3363 or email info@threephaseups.ca.
Request a quote: Delta Ultron HPH
Tell us the application and we reply within 4 business hours with the sizing, the right system, the installation and a written quote. Three-phase installs usually need a licensed electrician, so let us know if you have one.
Brand names are trademarks of their owners and are used only to identify the equipment we service. We are not the manufacturer and are not affiliated with it.
